  • LINE FILTER
  • EMI FILTER
  • PCBA/COIL A'SSY
  • FEEDTHROUGH
    FILM CAPACITORS
  • REACTOR
  • AUTOMOTIVE
    INDUCTOR
line filter img1

Common Mode coil

LINE FILTER which remove common mode noise on low-frequency band. Wound with more than two coil
which have high permeability such as Amorphous(Co) Ferrite(MnZn)and also same type of winding.
On common mode noise, magnetic flux occur strong inductance in same direction and about common
mode noise, magnetic flux offset each other and that remove effect of inductor.

MORE VIEW
line filter img2

Normal Mode coil

LINE FILTER which remove automode noise on high-frequency band.
To reduce core's saturation from power supply current
we use low permeability core such as Amorphous(Fe), MPP, Iron Powder..). Magnetic flux
gets one way by wounding on one side, and that control common-mode noise.

MORE VIEW
line filter img1

EMI FILTER

Using L/C's own specificity and
impedence gap which applied by machine, it’s a filter that
block and pass through frequency and certain section which someone request to use

MORE VIEW
line filter img1

PCBA/COIL A'SSY

특별한 주파수 대역을 차단하는 역할을 하는 필터 입니다. 간편한 배선 디자인으로 범용적으로 활용할 수 있습니다.
주로 홈네트워크 시스템에 적용되는 필터입니다.

MORE VIEW
line filter img1

Feedthrough Film Capacitors

As a capacitor for bypass,it’s a filter which role is
filtering all many kind of noise that come from power supply and impulse

MORE VIEW
line filter img1

Reactor

access circuit by DC, it control circuit's 'short-circuit current' and used for both reduce magnetic
coil heat and mechanical power by controlling 'starting current' when product is operating.
On 'rectifier unit' it inserts on DC side and use for reduce Direct Current's ripple factor.
Also its a part to protect the generator, transformer from heat and other machine

MORE VIEW
line filter img1

Automotive Inductor

Using by various magnetic material, it plans COIL
which is specialized by temperature, DC-BIAS, vibration.

MORE VIEW
